Product Features:
1、cold forged radiator, hollow cylindrical cross-section, increase the cooling area, electrical cooling cavity, radiator cavity light source multiple cooling structure;
2、 the design of special electrical cavity to eliminate the heat transfer with the light source cavity, and the use of hollow-type heat sink structure, increase the contact area with the air to form convection,a good solution to the power cooling problem, an increase of power and light source life;
3、transparent pieces of nano-tempered glass, light transmittance of up to 99%, high purity steel, strong resistance.
Applicable Area:
1、For explosion-proof high-ceiling plant lighting;
2、Suitable for explosive gas atmospheres Zone 1, Zone 2 places;
3、For Class IIA, IIB, IIC explosive gas atmospheres;
4、T1-T6 group temperature group.
Technical parameters
Input Voltage
AC100-240V 50/60Hz
Light Source
LED
EXD
ExdIICT6
IP
IP66
WF
WF2
CRI
≥80
CCT
3000K-6500K
Holder
G3/4
Order number | Power | Luminous(lm) | Dimensions(mm) |
LBCF4510-70 | 70W | 7000lm | φ330*438 |
LBCF4510-100 | 100W | 10000lm | φ330*438 |
LBCF4510-120 | 120W | 12000lm | φ330*438 |
LBCF4510-150 | 150W | 15000lm | φ330*438 |
