Product Feature:
1.Energy saving, no UV, infrared and mercury pollution, in line with ROHS requirements;
2.The base is made of all-aluminum die-casting process, which is good for heat dissipation when assembling LED lamps and can achieve the purpose of anti-corrosion;
3.Transparent cover with high transmittance PC material, light transmittance of more than 90%;
4.The entire lamp protection level of IP65, silicone waterproof, stainless steel screws with this section of the lamp to achieve the perfect waterproof effect, waterproof, dustproof, anti-corrosion (explosion-proof) structure makes this section lamps suitable for use in a variety of environments;
5.Isolation low-voltage constant current drive, with anti-over-current, over voltage, short circuit protection and other functions; safe, stable and reliable;
6.The use of imported light source and advanced cooling technology, the product MTBF up to 25000hr;
7.Can be frequently switched on and off, no flicker and glare phenomenon; while good color performance; seismic performance;
8.The appearance of simple and generous, fashionable and suitable for a variety of lighting.
Application Area:
Mainly used in the canopy, water room, warehouse, indoor and outdoor channel balcony, toilet and other regional lighting.
Technical parameters
Input Voltage
AC100-240V 50/60Hz
Light Source
LED
IP
IP20
CRI
≥80
CCT
3000K/4000K/6000K
Order number
Power
Luminous(lm)
Dimensions(mm)
LDC5131-20
20W
1700lm
φ315*100
LDC5131-30
30W
2550lm
φ315*100
